MEAN WELL RS-75-48 76.8W 48V 1.6A Enclosed Type

Part numberRS-75-48
Output voltage 48 V
Rated current 1.6 A
Rated power 76.8 W
$28.42Excluding tax and shipping
Ships in 3–5 business daysLead time is the time from order to dispatch, and does not include transit time.
Request bulk quote
RS-75 model selection table G3 Series
  • Genuine product Sourced through our documented supply chain.
  • Worldwide shipping Export documentation handled for you.
  • Commercial invoice Available for every order.
  • Specification support Talk to someone who reads datasheets.

Key specifications

Complete technical specifications
Output
Output voltage 48 V
Rated current 1.6 A
Rated power 76.8 W
AC input range 88–264 VAC
Typical efficiency 89.5 %
Mechanical
Operating temperature -25 to 70 °C
Dimensions (L × W × H) 129 × 98 × 38 mm

Is this model right for you?

RS-75-48 is distinguished within the RS-75 series primarily by its output voltage. Output voltage across the series: RS-75-3.3: 3.3V; RS-75-5: 5V; RS-75-12: 12V; RS-75-15: 15V; RS-75-24: 24V; RS-75-48: 48V. Rated power also differs: RS-75-48 provides 76.8W, compared with 75W (RS-75-15), 72W (RS-75-12), 60W (RS-75-5), and 49.5W (RS-75-3.3). Output current: RS-75-48 lists 1.6A, versus 3.2A (RS-75-24), 5A (RS-75-15), 6A (RS-75-12), 12A (RS-75-5), and 15A (RS-75-3.3).

Product overview

RS-75-48 is a MEAN WELL product in the RS-75 series, classified as Enclosed Type within the G3 Series family. It provides a 48V output with a listed output current of 1.6A and a rated power of 76.8W. Its specified typical efficiency is 89.5%, and its listed ripple and noise value is 200mVp-p. Among the RS-75 series models, RS-75-48 lists the highest output voltage and rated power.

Complete technical specifications

Rev. 2024-11-22
Output
Output voltage 48 V
Rated current 1.6 A
Rated power 76.8 W
Ripple & noise 200 mVp-p
Input
AC input range 88–264 VAC
DC input range 125–373 VDC
Frequency range 47–63 Hz
Typical efficiency 89.5 %
Environmental
Operating temperature -25 to 70 °C
Storage temperature -40 to 85 °C
Operating humidity 20–90 % RH
Vibration 10 ~ 500Hz, 5G 10min./1cycle, period for 60min. each along X, Y, Z axes
Mechanical
Dimensions (L × W × H) 129 × 98 × 38 mm
Net weight 410.0 g
Safety & compliance
Safety standards UL62368-1, TUV BS EN/EN62368-1, AS/NZS 62368.1, EAC TP TC 004 approved

These approvals are recorded for the series as a whole. Where a line names particular models or ratings, it applies only to those — read it against this part number, and ask us for the certificate if your approval process needs it.

Identification
Part number RS-75-48
Brand MEAN WELL
Category AC/DC Enclosed Type
Series RS-75

Approvals and compliance

From the manufacturer's datasheet for this series

United States

  • UL

    UL Listing or Recognition means UL Solutions tested samples against the applicable UL safety standard and audits the factory that builds them. A UL file number is the usual evidence an inspector or specifier asks for in North America.

Europe

  • TÜV

    A TÜV certificate is third-party testing against the European EN standard. It is the evidence behind a CE declaration rather than a replacement for it: CE remains the manufacturer's own declaration, and the TÜV report is what makes that declaration defensible.

Eurasian Economic Union

  • EAC

    Conformity with the Eurasian Economic Union technical regulations, covering Russia, Belarus, Kazakhstan, Armenia and Kyrgyzstan. TP TC 004 is the low-voltage regulation and TP TC 020 the electromagnetic-compatibility one, so which number appears tells you what was assessed.

Isolation and electromagnetic compatibility
Withstand voltage I/P-O/P:3KVAC I/P-FG:2KVAC O/P-FG:0.5KVAC
EMC emission Compliance to BS EN/EN55032 (CISPR32) Class B, BS EN/EN61000-3-2,-3, EAC TP TC 020
EMC immunity Compliance to BS EN/EN61000-4-2,3,4,5,6,8,11, BS EN/EN55035, BS EN/EN61000-6-2 (BS EN/EN50082-2), heavy industry level, EAC TP TC 020

Standards certified against

  • AS/NZS 62368.1
  • EN62368-1
  • UL62368-1
Read the datasheet's exact wording

UL62368-1, TUV BS EN/EN62368-1, AS/NZS 62368.1, EAC TP TC 004 approved

Reproduced unedited from the manufacturer's datasheet. Where an approval covers only some models, the wording says so. Ask us for the certificate itself if your approval process needs it.

Certificates

Certificate copy supplied with this model.

  • CE · R50453592

    100%
    CE certificate R50453592

    CE · Certificate number R50453592

Ordering & shipping information

Order and delivery terms
Part number RS-75-48
Minimum order quantity 1
Country of origin China
Typical packed weight 593 g
Unit weight 410 g

Downloads

RS-75 model comparison

View all models
ModelOutput voltageRated currentRated powerPriceAvailability
RS-75-55 V12 A60 W$28.42
Ships in 3–5 business days
RS-75-48 48 V1.6 A76.8 W$28.42
Ships in 3–5 business days
RS-75-2424 V3.2 A76.8 W$26.53
Ships in 3–5 business days

Output voltage: RS-75-48 provides 48V, compared with 24V (RS-75-24), 15V (RS-75-15), 12V (RS-75-12), 5V (RS-75-5), and 3.3V (RS-75-3.3).

Rated power: RS-75-48 provides 76.8W, compared with 75W (RS-75-15), 72W (RS-75-12), 60W (RS-75-5), and 49.5W (RS-75-3.3).

Ripple and noise: RS-75-48 lists 200mVp-p, compared with 120mVp-p (RS-75-12, RS-75-15, RS-75-24) and 80mVp-p (RS-75-5, RS-75-3.3).

Typical efficiency: RS-75-48 lists 89.5%, compared with 88.5% (RS-75-24), 86% (RS-75-15), 84.5% (RS-75-12), 79% (RS-75-5), and 75% (RS-75-3.3).
