MEAN WELL MSP-100-5 85W 5V 17A Enclosed Type

Part numberMSP-100-5
Output voltage 5 V
Rated current 17 A
Rated power 85 W
$85.27Excluding tax and shipping
Ships in 3–5 business daysLead time is the time from order to dispatch, and does not include transit time.
Request bulk quote
MSP-100 model selection table MSP Series
  • Genuine product Sourced through our documented supply chain.
  • Worldwide shipping Export documentation handled for you.
  • Commercial invoice Available for every order.
  • Specification support Talk to someone who reads datasheets.

Key specifications

Complete technical specifications
Output
Output voltage 5 V
Rated current 17 A
Rated power 85 W
AC input range 85–264 VAC
Typical efficiency 83 %
Mechanical
Operating temperature -40 to 60 °C
Power factor correction Supported
Dimensions (L × W × H) 159 × 97 × 38 mm

Is this model right for you?

MSP-100-5 lists a 5V output at 17A with 85W rated power. MSP-100-3.3 lists a lower 3.3V output at 20A with 66W rated power, while MSP-100-7.5 lists 7.5V at 13.5A with 101.3W. Higher-voltage versions list different figures: MSP-100-12 lists 12V at 8.5A and 102W, and MSP-100-48 lists 48V at 2.2A and 105.6W. Listed typical efficiency values are MSP-100-3.3: 78%; MSP-100-5: 83%; MSP-100-7.5: 84%; MSP-100-12: 87.5%; MSP-100-15: 88%; MSP-100-24: 88.5%; MSP-100-36: 89%; MSP-100-48: 90%.

Product overview

MEAN WELL MSP-100-5 is an Enclosed Type product in the MEAN WELL MSP Series, belonging to the MSP-100 series. It lists a 5V output with a 17A output current and an 85W rated power. The output adjustment range is listed as 4.75~5.8V, typical efficiency is 83%, and ripple and noise are listed at 80mVp-p. Across the MSP-100 series, listed output voltages span from 3.3V on MSP-100-3.3 up to 48V on MSP-100-48, with listed output currents of 20A and 2.2A at those respective ends.

Complete technical specifications

Rev. 2025-03-17
Output
Output voltage 5 V
Rated current 17 A
Rated power 85 W
Voltage adjustment range 4.75–5.8 V
Ripple & noise 80 mVp-p
Input
AC input range 85–264 VAC
DC input range 120–370 VDC
Frequency range 47–63 Hz
Typical efficiency 83 %
Power factor 0.95
Power factor correction Supported
Environmental
Operating temperature -40 to 60 °C
Storage temperature -40 to 85 °C
Operating humidity 20–90 % RH
Vibration 10 ~ 500Hz, 5G 10min./1cycle, 60min. each along X, Y, Z axes
Mechanical
Dimensions (L × W × H) 159 × 97 × 38 mm
Net weight 550.0 g
Safety & compliance
Safety standards IEC 60601-1:2005+A1+A2, ANSI/AAMI ES 60601-1:2005+A2, CAN/CSA C22.2 No. 60601-1:2014+A2, EAC TP TC 004 approved Design refer to BS EN/EN60335-1, BS EN/EN 62368-1(by request)

These approvals are recorded for the series as a whole. Where a line names particular models or ratings, it applies only to those — read it against this part number, and ask us for the certificate if your approval process needs it.

Identification
Part number MSP-100-5
Brand MEAN WELL
Category AC/DC Enclosed Type
Series MSP-100

Approvals and compliance

From the manufacturer's datasheet for this series

Canada

  • CSA

    Certification to a CSA C22.2 standard, the Canadian counterpart of the UL series. Datasheets cite the specific C22.2 number, which is how you tell a power-supply certificate from a luminaire-controlgear one.

Eurasian Economic Union

  • EAC

    Conformity with the Eurasian Economic Union technical regulations, covering Russia, Belarus, Kazakhstan, Armenia and Kyrgyzstan. TP TC 004 is the low-voltage regulation and TP TC 020 the electromagnetic-compatibility one, so which number appears tells you what was assessed.

Isolation and electromagnetic compatibility
Withstand voltage I/P-O/P:4KVAC I/P-FG:2KVAC O/P-FG:0.5KVAC
EMC emission Compliance to BS EN/EN55011 (CISPR11) Class B, BS EN/EN61000-3-2,-3, EAC TP TC 020
EMC immunity Compliance to BS EN/EN61000-4-2,3,4,5,6,8,11, BS EN/EN55035,BS EN/EN60601-1-2, EAC TP TC 020

Standards certified against

  • ANSI/AAMI ES 60601-1
  • IEC 60601-1

Designed to reference

The datasheet lists these as design references. The series was built to them but has not been certified to them, so do not treat them as approvals.

BS EN/EN60335-1, BS EN/EN 62368-1(by request)

Read the datasheet's exact wording

IEC 60601-1:2005+A1+A2, ANSI/AAMI ES 60601-1:2005+A2, CAN/CSA C22.2 No. 60601-1:2014+A2, EAC TP TC 004 approved Design refer to BS EN/EN60335-1, BS EN/EN 62368-1(by request)

Reproduced unedited from the manufacturer's datasheet. Where an approval covers only some models, the wording says so. Ask us for the certificate itself if your approval process needs it.

Certificates

Certificate copy supplied with this model.

  • CE · R50453592

    100%
    CE certificate R50453592

    CE · Certificate number R50453592

Ordering & shipping information

Order and delivery terms
Part number MSP-100-5
Minimum order quantity 1
Country of origin China
Warranty 5-year limited warranty, subject to the conditions in MEAN WELL's published warranty statement.
Typical packed weight 746 g
Unit weight 550 g

Downloads

MSP-100 model comparison

View all models
ModelOutput voltageRated currentRated powerPriceAvailability
MSP-100-5 5 V17 A85 W$85.27
Ships in 3–5 business days
MSP-100-1212 V8.5 A102 W$85.27
Ships in 3–5 business days
MSP-100-7.57.5 V13.5 A101.3 W$85.27
Ships in 3–5 business days

MSP-100-5 lists a 5V output at 17A; MSP-100-3.3 lists 3.3V at 20A, and MSP-100-48 lists 48V at 2.2A.

MSP-100-5 lists 85W rated power; MSP-100-3.3 lists 66W, and MSP-100-24 lists 108W.

MSP-100-5 lists 83% typical efficiency and 80mVp-p ripple and noise; MSP-100-48 lists 90% typical efficiency and 240mVp-p ripple and noise.
