MEAN WELL LRS-600-15 600W 15V 40A Enclosed Type
Procurement confidence
- Genuine product Sourced through our documented supply chain.
- Worldwide shipping Export documentation handled for you.
- Commercial invoice Available for every order.
- Specification support Talk to someone who reads datasheets.
Key specifications
Complete technical specifications| Output voltage | 15 V |
|---|---|
| Rated current | 40 A |
| Rated power | 600 W |
| Typical efficiency | 90 % |
| Operating temperature | -20 to 65 °C |
|---|---|
| Dimensions (L × W × H) | 225 × 124 × 41 mm |
Is this model right for you?
Product overview
Complete technical specifications
Rev. 2025-09-12| Output voltage | 15 V |
|---|---|
| Rated current | 40 A |
| Rated power | 600 W |
| Voltage adjustment range | 14.25–16.5 V |
| Ripple & noise | 200 mVp-p |
| AC input range | 90 ~ 132VAC / 180 ~ 264VAC by switch 255 ~ 370VDC (swith on 230VAC) |
|---|---|
| DC input range | 255–370 VDC |
| Frequency range | 47–63 Hz |
| Typical efficiency | 90 % |
| Over voltage | Protected |
|---|---|
| Over temperature | Protected |
| Operating temperature | -20 to 65 °C |
|---|---|
| Storage temperature | -40 to 85 °C |
| Operating humidity | 20–90 % RH |
| Vibration | 10 ~ 500Hz, 5G 10min./1cycle, 60min. each along X, Y, Z axes |
| Dimensions (L × W × H) | 225 × 124 × 41 mm |
|---|---|
| Net weight | 950.0 g |
| Safety standards | BS IEC/UL 62368-1, EAC TP TC 004, KC62368-1(except for 5V), BIS IS13252(Part1):2010/IEC60950-1: 2005 ,BSMI CNS15598-1,GB 4943.1,BS EN/EN61558-1,BS EN/EN61558-2-16 approved, Designed by AS/NZS 61558.1/2.16, AS/NZS 62368.1 (datasheet note applies) |
|---|
These approvals are recorded for the series as a whole. Where a line names particular models or ratings, it applies only to those — read it against this part number, and ask us for the certificate if your approval process needs it.
| Part number | LRS-600-15 |
|---|---|
| Brand | MEAN WELL |
| Category | AC/DC Enclosed Type |
| Series | LRS-600 |
Approvals and compliance
From the manufacturer's datasheet for this seriesUnited States
- UL
UL Listing or Recognition means UL Solutions tested samples against the applicable UL safety standard and audits the factory that builds them. A UL file number is the usual evidence an inspector or specifier asks for in North America.
Taiwan
- BSMI
Taiwan's mandatory inspection mark, issued against a CNS standard. CNS 15598-1 is the CNS transposition of IEC 62368-1, which is why the two numbers usually appear together.
Eurasian Economic Union
- EAC
Conformity with the Eurasian Economic Union technical regulations, covering Russia, Belarus, Kazakhstan, Armenia and Kyrgyzstan. TP TC 004 is the low-voltage regulation and TP TC 020 the electromagnetic-compatibility one, so which number appears tells you what was assessed.
India
- BIS
Registration under India's Compulsory Registration Scheme, against an IS standard. IS 13252 is the Indian transposition of IEC 60950-1 and IS 15885 of IEC 61347, so the IS number identifies the product category.
South Korea
- KC
Korea Certification, mandatory for electrical equipment in scope. The KC number mirrors the IEC standard it is based on, so KC 62368-1 is assessment against the Korean adoption of IEC 62368-1.
Covers only part of this series: except for 5V
An approval above is held by only some models in this series. The datasheet's own wording is quoted beside the mark; read it against this part number, and ask us for the certificate if your approval process needs it.
| Withstand voltage | I/P-O/P:3.75KVAC I/P-FG:2KVAC O/P-FG:0.5KVAC |
|---|---|
| EMC emission | Compliance to EAC TP TC 020, BSMI CNS15936,KC KSC 9832, KSC 9835 |
| EMC immunity | Compliance to EAC TP TC 020,KC KSC 9832, KSC 9835 |
Standards certified against
- CNS15598-1
- EN61558-1
- EN61558-2-16
- GB 4943.1
- IEC60950-1
- IS13252
- KC62368-1
- UL 62368-1
Designed to reference
The datasheet lists these as design references. The series was built to them but has not been certified to them, so do not treat them as approvals.
AS/NZS 61558.1/2.16, AS/NZS 62368.1
Read the datasheet's exact wording
BS IEC/UL 62368-1, EAC TP TC 004, KC62368-1(except for 5V), BIS IS13252(Part1):2010/IEC60950-1: 2005 ,BSMI CNS15598-1,GB 4943.1,BS EN/EN61558-1,BS EN/EN61558-2-16 approved, Designed by AS/NZS 61558.1/2.16, AS/NZS 62368.1 (datasheet note applies)
Reproduced unedited from the manufacturer's datasheet. Where an approval covers only some models, the wording says so. Ask us for the certificate itself if your approval process needs it.
Certificates
Certificate copy supplied with this model.
Enlarge
CE · Certificate number R50453592
Ordering & shipping information
| Part number | LRS-600-15 |
|---|---|
| Minimum order quantity | 1 |
| Country of origin | China |
| Typical packed weight | 1183 g |
| Unit weight | 950 g |
LRS-600 model comparison
View all models| Model | Output voltage | Rated current | Rated power | Price | Availability |
|---|---|---|---|---|---|
| LRS-600-24 | 24 V | 25 A | 600 W | $79.90 |
Ships in 3–5 business days
|
| LRS-600-15 Currently viewing | 15 V | 40 A | 600 W | $86.22 |
Ships in 3–5 business days
|
| LRS-600-27 | 27 V | 22.2 A | 599.4 W | $86.22 |
Ships in 3–5 business days
|
Request a bulk quote
Tell us the quantity and target date and we will come back with pricing, lead time and stock position for this part number.
- 1 We confirm the part number and quantity against current stock.
- 2 You receive pricing, lead time and freight options by email.
- 3 Approve the quotation and we issue the invoice and shipping documents.
Request a quote for LRS-600-15
Confirm quantity and destination and we will come back with pricing and lead time.
Technical data source
- Primary source
- MEAN WELL
- Datasheet revision
- 2025-09-12
- Last verified
View the manufacturer datasheet How we source and verify product data
Specifications are transcribed from the manufacturer datasheet and are subject to change without notice. The current manufacturer datasheet governs in case of any discrepancy.
