MEAN WELL UHP-1500-48 1512W 48V 31.5A Enclosed Type

Part numberUHP-1500-48
Output voltage 48 V
Rated current 31.5 A
Rated power 1512 W
$630.09Excluding tax and shipping
Ships in 3–5 business daysLead time is the time from order to dispatch, and does not include transit time.
Request bulk quote
UHP-1500 model selection table UHP Series
  • Genuine product Sourced through our documented supply chain.
  • Worldwide shipping Export documentation handled for you.
  • Commercial invoice Available for every order.
  • Specification support Talk to someone who reads datasheets.

Key specifications

Complete technical specifications
Output
Output voltage 48 V
Rated current 31.5 A
Rated power 1512 W
AC input range 90–264 VAC
Typical efficiency 96 %
Mechanical
Cooling Free-air convection
Operating temperature -30 to 70 °C
Dimensions (L × W × H) 290 × 140 × 41 mm

Is this model right for you?

Within the UHP-1500 series, UHP-1500-48 lists 48 V output, 31.5 A output current, 1512 W rated power, 96% typical efficiency, and 350mVp-p ripple and noise. UHP-1500-24 lists 24 V output, 62.5 A output current, 1500 W rated power, 95% typical efficiency, and 240mVp-p ripple and noise.

Product overview

The UHP-1500-48 provides a 48 V output at 31.5 A with 1512 W rated power. Its input voltage range is 90 ~ 264Vac 250 ~ 370Vdc, with a frequency range of 47 ~ 63Hz. Typical efficiency is 96%, and ripple and noise is 350mVp-p. Dimensions are 290 × 140 × 41 mm and net weight is 2510 g.

Where this model fits

The UHP-1500-48 is used in Industrial Automation, Motor Drives, Security & Surveillance, Telecom & Datacom, and Test & Measurement. Its operating temperature range is -30 to 70 °C, humidity range is 20 to 90%, and net weight is 2510 g.

Complete technical specifications

Rev. 2025-12-05
Output
Output voltage 48 V
Rated current 31.5 A
Rated power 1512 W
Ripple & noise 350 mVp-p
Input
AC input range 90–264 VAC
DC input range 250–370 VDC
Frequency range 47–63 Hz
Typical efficiency 96 %
Environmental
Operating temperature -30 to 70 °C
Storage temperature -40 to 85 °C
Operating humidity 20–90 % RH
Vibration 10 ~ 500Hz, 5G 10min./1cycle, 60min. each along X, Y, Z axes
Mechanical
Dimensions (L × W × H) 290 × 140 × 41 mm
Net weight 2510.0 g
Cooling Free-air convection
Fan Not supported
Safety & compliance
Safety standards UL62368-1, DEKRA BS EN/EN62368-1, EAC TP TC 004 approved

These approvals are recorded for the series as a whole. Where a line names particular models or ratings, it applies only to those — read it against this part number, and ask us for the certificate if your approval process needs it.

Identification
Part number UHP-1500-48
Brand MEAN WELL
Category AC/DC Enclosed Type
Series UHP-1500

Approvals and compliance

From the manufacturer's datasheet for this series

United States

  • UL

    UL Listing or Recognition means UL Solutions tested samples against the applicable UL safety standard and audits the factory that builds them. A UL file number is the usual evidence an inspector or specifier asks for in North America.

Europe

  • DEKRA

    DEKRA is a European notified body; a DEKRA certificate on a datasheet is third-party testing against the cited EN standard, equivalent in standing to a TÜV one.

Eurasian Economic Union

  • EAC

    Conformity with the Eurasian Economic Union technical regulations, covering Russia, Belarus, Kazakhstan, Armenia and Kyrgyzstan. TP TC 004 is the low-voltage regulation and TP TC 020 the electromagnetic-compatibility one, so which number appears tells you what was assessed.

Isolation and electromagnetic compatibility
Withstand voltage I/P-O/P:3.75KVac I/P-FG:2KVac O/P-FG:1.25KVac
Isolation resistance I/P-O/P, I/P-FG,O/P-FG:100M Ohms/500Vdc/25℃/ 70%RH

Standards certified against

  • EN62368-1
  • UL62368-1
Read the datasheet's exact wording

UL62368-1, DEKRA BS EN/EN62368-1, EAC TP TC 004 approved

Reproduced unedited from the manufacturer's datasheet. Where an approval covers only some models, the wording says so. Ask us for the certificate itself if your approval process needs it.

Certificates

Certificate copy supplied with this model.

  • CE · R50453592

    100%
    CE certificate R50453592

    CE · Certificate number R50453592

Ordering & shipping information

Order and delivery terms
Part number UHP-1500-48
Minimum order quantity 1
Country of origin China
Typical packed weight 2766 g
Unit weight 2510 g

Downloads

UHP-1500 model comparison

View all models
ModelOutput voltageRated currentRated powerPriceAvailability
UHP-1500-48 48 V31.5 A1512 W$630.09
Ships in 3–5 business days
UHP-1500-2424 V62.5 A1500 W$586.82
Ships in 3–5 business days

UHP-1500-48 lists 48 V output and 31.5 A output current; UHP-1500-24 lists 24 V output and 62.5 A output current.

UHP-1500-48 lists 1512 W rated power and 96% typical efficiency; UHP-1500-24 lists 1500 W rated power and 95% typical efficiency.

UHP-1500-48 lists 350mVp-p ripple and noise; UHP-1500-24 lists 240mVp-p ripple and noise.
