MEAN WELL RT-65A 66.1W 5V 6A Enclosed Type

Part numberRT-65A
Output voltage 5 V
Rated current 6 A
Rated power 66.1 W
$34.74Excluding tax and shipping
Ships in 3–5 business daysLead time is the time from order to dispatch, and does not include transit time.
Request bulk quote
RT-65 model selection table G3 Series
  • Genuine product Sourced through our documented supply chain.
  • Worldwide shipping Export documentation handled for you.
  • Commercial invoice Available for every order.
  • Specification support Talk to someone who reads datasheets.

Key specifications

Complete technical specifications
Output
Output voltage 5 V
Rated current 6 A
Rated power 66.1 W
AC input range 88–264 VAC
Typical efficiency 76 %
Mechanical
Operating temperature -25 to 70 °C
Dimensions (L × W × H) 129 × 98 × 38 mm

Is this model right for you?

Within the RT-65 series, the RT-65A lists 66.1 W, 76%. By comparison RT-65B lists 64.6 W, 76%; RT-65C lists 65.5 W, 77%; RT-65D lists 68 W, 78%. Select the model whose rated power matches the installation.

Product overview

The RT-65A belongs to the MEAN WELL RT-65 series and is classified as an AC/DC Enclosed Type product in the G3 Series family. It measures 129 × 98 × 38 mm and has a net weight of 440 g. The input frequency range is 47 ~ 63Hz, and the operating temperature range is -25 to 70 °C.

Where this model fits

The RT-65A is used in Industrial Automation and Security & Surveillance applications. Its operating temperature range is -25 to 70 °C, and its dimensions are 129 × 98 × 38 mm with a net weight of 440 g.

Complete technical specifications

Rev. 2024-11-22
Output
Output voltage 5 V
Rated current 6 A
Rated power 66.1 W
Input
AC input range 88–264 VAC
DC input range 125–373 VDC
Frequency range 47–63 Hz
Typical efficiency 76 %
Environmental
Operating temperature -25 to 70 °C
Storage temperature -40 to 85 °C
Operating humidity 20–90 % RH
Vibration 10 ~ 500Hz, 5G 10min./1cycle, period for 60min. each along X, Y, Z axes
Mechanical
Dimensions (L × W × H) 129 × 98 × 38 mm
Net weight 440.0 g
Safety & compliance
Safety standards UL62368-1, TUV BS EN/EN62368-1, BIS IS 13252(Part 1):2010/IEC 60950-1:2005, EAC TP TC 004 approved

These approvals are recorded for the series as a whole. Where a line names particular models or ratings, it applies only to those — read it against this part number, and ask us for the certificate if your approval process needs it.

Identification
Part number RT-65A
Brand MEAN WELL
Category AC/DC Enclosed Type
Series RT-65

Approvals and compliance

From the manufacturer's datasheet for this series

United States

  • UL

    UL Listing or Recognition means UL Solutions tested samples against the applicable UL safety standard and audits the factory that builds them. A UL file number is the usual evidence an inspector or specifier asks for in North America.

Europe

  • TÜV

    A TÜV certificate is third-party testing against the European EN standard. It is the evidence behind a CE declaration rather than a replacement for it: CE remains the manufacturer's own declaration, and the TÜV report is what makes that declaration defensible.

Eurasian Economic Union

  • EAC

    Conformity with the Eurasian Economic Union technical regulations, covering Russia, Belarus, Kazakhstan, Armenia and Kyrgyzstan. TP TC 004 is the low-voltage regulation and TP TC 020 the electromagnetic-compatibility one, so which number appears tells you what was assessed.

India

  • BIS

    Registration under India's Compulsory Registration Scheme, against an IS standard. IS 13252 is the Indian transposition of IEC 60950-1 and IS 15885 of IEC 61347, so the IS number identifies the product category.

Isolation and electromagnetic compatibility
Withstand voltage I/P-O/P:3KVAC I/P-FG:2KVAC O/P-FG:0.5KVAC
EMC emission Compliance to BS EN/EN55032 (CISPR32) Class B, BS EN/EN61000-3-2,-3, EAC TP TC 020
EMC immunity Compliance to BS EN/EN61000-4-2,3,4,5,6,8,11, BS EN/EN55035,BS EN/EN61000-6-2 (BS EN/EN50082-2), heavy industry level, EAC TP TC 020

Standards certified against

  • EN62368-1
  • IEC 60950-1
  • IS 13252
  • UL62368-1
Read the datasheet's exact wording

UL62368-1, TUV BS EN/EN62368-1, BIS IS 13252(Part 1):2010/IEC 60950-1:2005, EAC TP TC 004 approved

Reproduced unedited from the manufacturer's datasheet. Where an approval covers only some models, the wording says so. Ask us for the certificate itself if your approval process needs it.

Certificates

Certificate copy supplied with this model.

  • CE · R50453592

    100%
    CE certificate R50453592

    CE · Certificate number R50453592

Ordering & shipping information

Order and delivery terms
Part number RT-65A
Minimum order quantity 1
Country of origin China
Typical packed weight 590 g
Unit weight 440 g

Downloads

RT-65 model comparison

View all models
ModelOutput voltageRated currentRated powerPriceAvailability
RT-65B5 V5 A64.6 W$32.53
Ships in 3–5 business days
RT-65A 5 V6 A66.1 W$34.74
Ships in 3–5 business days

RT-65A: 6 A output current; RT-65D: 4 A; RT-65B and RT-65C: 5 A.

RT-65A: 66.1 W rated power; the rest of the series runs 64.6 W to 68 W.

RT-65A: 76% typical efficiency; RT-65C: 77%; RT-65D: 78%.

Request a bulk quote

Tell us the quantity and target date and we will come back with pricing, lead time and stock position for this part number.

  1. 1 We confirm the part number and quantity against current stock.
  2. 2 You receive pricing, lead time and freight options by email.
  3. 3 Approve the quotation and we issue the invoice and shipping documents.

Request a quote for RT-65A

Confirm quantity and destination and we will come back with pricing and lead time.

Quoting RT-65A View
Have a BOM? Reply to our confirmation email with the file attached.
We use your details only to answer this request.

Technical data source

Primary source
MEAN WELL
Datasheet revision
2024-11-22
Last verified

View the manufacturer datasheet How we source and verify product data

Specifications are transcribed from the manufacturer datasheet and are subject to change without notice. The current manufacturer datasheet governs in case of any discrepancy.
