MEAN WELL RSP-1600-48 1608W 48V 33.5A Programmable Power

Part numberRSP-1600-48
Output voltage 48 V
Rated current 33.5 A
Rated power 1608 W
$755.79Excluding tax and shipping
Ships in 3–5 business daysLead time is the time from order to dispatch, and does not include transit time.
Request bulk quote
RSP-1600 model selection table RSP-750~3000
  • Genuine product Sourced through our documented supply chain.
  • Worldwide shipping Export documentation handled for you.
  • Commercial invoice Available for every order.
  • Specification support Talk to someone who reads datasheets.

Key specifications

Complete technical specifications
Output
Output voltage 48 V
Rated current 33.5 A
Rated power 1608 W
AC input range 90–264 VAC
Typical efficiency 93 %
Mechanical
Operating temperature -30 to 70 °C
Power factor correction Supported
Dimensions (L × W × H) 300 × 85 × 41 mm

Is this model right for you?

Within the RSP-1600 series, the RSP-1600-48 differs from siblings by output voltage, output current, rated power, efficiency, ripple and noise, and output adjustment range. RSP-1600-48: 48V, 33.5A, 1608W, 93%, 300mVp-p, 47.5 ~ 58.8V. RSP-1600-12: 12V, 125A, 1500W, 89%, 150mVp-p, 11.5 ~ 15V. RSP-1600-24: 24V, 67A, 91.5%, 200mVp-p, 23.5 ~ 30V. RSP-1600-27: 27V, 59A, 1593W, 92%, 200mVp-p, 26.5 ~ 33.5V. RSP-1600-36: 36V, 44.5A, 1602W, 92%, 250mVp-p, 35.5 ~ 45V.

Product overview

The RSP-1600-48 provides a 48V output with 33.5A output current and 1608W rated power. The output adjustment range is 47.5 ~ 58.8V, and typical efficiency is 93%. Ripple and noise is 300mVp-p. The input voltage range is 90 ~ 264VAC 250 ~ 370VDC with a frequency range of 47 ~ 63Hz. Dimensions are 300 × 85 × 41 mm and net weight is 2100g.

Where this model fits

The RSP-1600-48 is used in Test & Measurement. Its 48V output and 33.5A output current provide 1608W rated power. The output adjustment range is 47.5 ~ 58.8V, and ripple and noise is 300mVp-p. Typical efficiency is 93%.

Complete technical specifications

Rev. 2026-06-15
Output
Output voltage 48 V
Rated current 33.5 A
Rated power 1608 W
Voltage adjustment range 47.5–58.8 V
Ripple & noise 300 mVp-p
Input
AC input range 90–264 VAC
DC input range 250–370 VDC
Frequency range 47–63 Hz
Typical efficiency 93 %
Power factor 0.97
Power factor correction Supported
Environmental
Operating temperature -30 to 70 °C
Storage temperature -40 to 85 °C
Operating humidity 20–90 % RH
Vibration 10 ~ 500Hz, 2G 10min./1cycle, 60min. each along X, Y, Z axes
Mechanical
Dimensions (L × W × H) 300 × 85 × 41 mm
Net weight 2100.0 g
Safety & compliance
Safety standards UL62368-1, CAN/CSA C22.2 No. 62368-1, TUV BS EN/EN62368-1, BSMI CNS15598-1, AS/NZS62368.1, EAC TP TC 004 approved

These approvals are recorded for the series as a whole. Where a line names particular models or ratings, it applies only to those — read it against this part number, and ask us for the certificate if your approval process needs it.

Identification
Part number RSP-1600-48
Brand MEAN WELL
Category AC/DC Programmable Power
Series RSP-1600

Approvals and compliance

From the manufacturer's datasheet for this series

United States

  • UL

    UL Listing or Recognition means UL Solutions tested samples against the applicable UL safety standard and audits the factory that builds them. A UL file number is the usual evidence an inspector or specifier asks for in North America.

Canada

  • CSA

    Certification to a CSA C22.2 standard, the Canadian counterpart of the UL series. Datasheets cite the specific C22.2 number, which is how you tell a power-supply certificate from a luminaire-controlgear one.

Europe

  • TÜV

    A TÜV certificate is third-party testing against the European EN standard. It is the evidence behind a CE declaration rather than a replacement for it: CE remains the manufacturer's own declaration, and the TÜV report is what makes that declaration defensible.

Taiwan

  • BSMI

    Taiwan's mandatory inspection mark, issued against a CNS standard. CNS 15598-1 is the CNS transposition of IEC 62368-1, which is why the two numbers usually appear together.

Eurasian Economic Union

  • EAC

    Conformity with the Eurasian Economic Union technical regulations, covering Russia, Belarus, Kazakhstan, Armenia and Kyrgyzstan. TP TC 004 is the low-voltage regulation and TP TC 020 the electromagnetic-compatibility one, so which number appears tells you what was assessed.

Isolation and electromagnetic compatibility
Withstand voltage I/P-O/P:3KVAC I/P-FG:2KVAC O/P-FG:1.5KVAC
EMC emission Parameter Standard Test Level / Note

Standards certified against

  • AS/NZS62368.1
  • CNS15598-1
  • EN62368-1
  • UL62368-1
Read the datasheet's exact wording

UL62368-1, CAN/CSA C22.2 No. 62368-1, TUV BS EN/EN62368-1, BSMI CNS15598-1, AS/NZS62368.1, EAC TP TC 004 approved

Reproduced unedited from the manufacturer's datasheet. Where an approval covers only some models, the wording says so. Ask us for the certificate itself if your approval process needs it.

Certificates

Certificate copy supplied with this model.

  • CE · R50453592

    100%
    CE certificate R50453592

    CE · Certificate number R50453592

Ordering & shipping information

Order and delivery terms
Part number RSP-1600-48
Minimum order quantity 1
Country of origin China
Typical packed weight 2491 g
Unit weight 2100 g

Downloads

RSP-1600 model comparison

View all models
ModelOutput voltageRated currentRated powerPriceAvailability
RSP-1600-48 48 V33.5 A1608 W$755.79
Ships in 3–5 business days
RSP-1600-2727 V59 A1593 W$755.79
Ships in 3–5 business days
RSP-1600-1212 V125 A1500 W$755.79
Ships in 3–5 business days

RSP-1600-48 lists 48V output and 33.5A output current; RSP-1600-12 lists 12V output and 125A output current.

RSP-1600-48 lists 1608W rated power and 93% typical efficiency; RSP-1600-24 lists 91.5% typical efficiency.

RSP-1600-48 lists 300mVp-p ripple and noise; RSP-1600-36 lists 250mVp-p ripple and noise.

RSP-1600-48 lists 47.5 ~ 58.8V output adjustment range; RSP-1600-27 lists 26.5 ~ 33.5V output adjustment range.

Request a bulk quote

Tell us the quantity and target date and we will come back with pricing, lead time and stock position for this part number.

  1. 1 We confirm the part number and quantity against current stock.
  2. 2 You receive pricing, lead time and freight options by email.
  3. 3 Approve the quotation and we issue the invoice and shipping documents.

Request a quote for RSP-1600-48

Confirm quantity and destination and we will come back with pricing and lead time.

Quoting RSP-1600-48 View
Have a BOM? Reply to our confirmation email with the file attached.
We use your details only to answer this request.

Technical data source

Primary source
MEAN WELL
Datasheet revision
2026-06-15
Last verified

View the manufacturer datasheet How we source and verify product data

Specifications are transcribed from the manufacturer datasheet and are subject to change without notice. The current manufacturer datasheet governs in case of any discrepancy.
