MEAN WELL RS-100-12 102W 12V 8.5A Enclosed Type

Part numberRS-100-12
Output voltage 12 V
Rated current 8.5 A
Rated power 102 W
$35.37Excluding tax and shipping
Ships in 3–5 business daysLead time is the time from order to dispatch, and does not include transit time.
Request bulk quote
RS-100 model selection table G3 Series
  • Genuine product Sourced through our documented supply chain.
  • Worldwide shipping Export documentation handled for you.
  • Commercial invoice Available for every order.
  • Specification support Talk to someone who reads datasheets.

Key specifications

Complete technical specifications
Output
Output voltage 12 V
Rated current 8.5 A
Rated power 102 W
AC input range 88–264 VAC
Typical efficiency 81 %
Mechanical
Operating temperature -25 to 70 °C
Dimensions (L × W × H) 159 × 97 × 38 mm

Is this model right for you?

Within the RS-100 series, the RS-100-12 differs from siblings by output voltage, output current, rated power, efficiency, and ripple and noise. RS-100-12: 12 V, 8.5 A, 102 W, 81%, 120 mVp-p. RS-100-15: 15 V, 7 A, 105 W, 82%. RS-100-24: 24 V, 4.5 A, 108 W, 84%. RS-100-48: 48 V, 2.3 A, 110.4 W, 84%, 200 mVp-p.

Product overview

The RS-100-12 is an AC/DC Enclosed Type product in the RS-100 series. It provides a 12 V output at 8.5 A with 102 W rated power. Typical efficiency is 81%, ripple and noise is 120 mVp-p, and the input frequency range is 47 ~ 63 Hz. Dimensions are 159 × 97 × 38 mm and net weight is 600 g.

Where this model fits

The RS-100-12 is used in Industrial Automation, Motor Drives, Security & Surveillance, Telecom & Datacom, and Test & Measurement applications. Its 12 V output and 8.5 A output current are the electrical characteristics supplied for this model.

Complete technical specifications

Rev. 2024-11-22
Output
Output voltage 12 V
Rated current 8.5 A
Rated power 102 W
Ripple & noise 120 mVp-p
Input
AC input range 88–264 VAC
DC input range 125–373 VDC
Frequency range 47–63 Hz
Typical efficiency 81 %
Environmental
Operating temperature -25 to 70 °C
Storage temperature -40 to 85 °C
Operating humidity 20–90 % RH
Vibration 10 ~ 500Hz, 5G 10min./1cycle, period for 60min. each along X, Y, Z axes
Mechanical
Dimensions (L × W × H) 159 × 97 × 38 mm
Net weight 600.0 g
Safety & compliance
Safety standards UL62368-1, TUV BS EN/EN62368-1, AS/NZS 62368.1, EAC TP TC 004 approved

These approvals are recorded for the series as a whole. Where a line names particular models or ratings, it applies only to those — read it against this part number, and ask us for the certificate if your approval process needs it.

Identification
Part number RS-100-12
Brand MEAN WELL
Category AC/DC Enclosed Type
Series RS-100

Approvals and compliance

From the manufacturer's datasheet for this series

United States

  • UL

    UL Listing or Recognition means UL Solutions tested samples against the applicable UL safety standard and audits the factory that builds them. A UL file number is the usual evidence an inspector or specifier asks for in North America.

Europe

  • TÜV

    A TÜV certificate is third-party testing against the European EN standard. It is the evidence behind a CE declaration rather than a replacement for it: CE remains the manufacturer's own declaration, and the TÜV report is what makes that declaration defensible.

Eurasian Economic Union

  • EAC

    Conformity with the Eurasian Economic Union technical regulations, covering Russia, Belarus, Kazakhstan, Armenia and Kyrgyzstan. TP TC 004 is the low-voltage regulation and TP TC 020 the electromagnetic-compatibility one, so which number appears tells you what was assessed.

Isolation and electromagnetic compatibility
Withstand voltage I/P-O/P:3KVAC I/P-FG:2KVAC O/P-FG:0.5KVAC
EMC emission Compliance to BS EN/EN55032 (CISPR32) Class B, BS EN/EN61000-3-2,-3, EAC TP TC 020
EMC immunity Compliance to BS EN/EN61000-4-2,3,4,5,6,8,11, BS EN/EN55035, BS EN/EN61000-6-2 (BS EN/EN50082-2), heavy industry level, EAC TP TC 020

Standards certified against

  • AS/NZS 62368.1
  • EN62368-1
  • UL62368-1
Read the datasheet's exact wording

UL62368-1, TUV BS EN/EN62368-1, AS/NZS 62368.1, EAC TP TC 004 approved

Reproduced unedited from the manufacturer's datasheet. Where an approval covers only some models, the wording says so. Ask us for the certificate itself if your approval process needs it.

Certificates

Certificate copy supplied with this model.

  • CE · R50453592

    100%
    CE certificate R50453592

    CE · Certificate number R50453592

Ordering & shipping information

Order and delivery terms
Part number RS-100-12
Minimum order quantity 1
Country of origin China
Typical packed weight 792 g
Unit weight 600 g

Downloads

RS-100 model comparison

View all models
ModelOutput voltageRated currentRated powerPriceAvailability
RS-100-4848 V2.3 A110.4 W$37.90
Ships in 3–5 business days
RS-100-12 12 V8.5 A102 W$35.37
Ships in 3–5 business days
RS-100-1515 V7 A105 W$37.90
Ships in 3–5 business days

RS-100-12 provides 12 V output and 8.5 A output current; RS-100-15 provides 15 V output and 7 A output current.

RS-100-12 provides 102 W rated power and 81% typical efficiency; RS-100-24 provides 108 W rated power and 84% typical efficiency.

RS-100-12 provides 120 mVp-p ripple and noise; RS-100-48 provides 200 mVp-p ripple and noise.

Request a bulk quote

Tell us the quantity and target date and we will come back with pricing, lead time and stock position for this part number.

  1. 1 We confirm the part number and quantity against current stock.
  2. 2 You receive pricing, lead time and freight options by email.
  3. 3 Approve the quotation and we issue the invoice and shipping documents.

Request a quote for RS-100-12

Confirm quantity and destination and we will come back with pricing and lead time.

Quoting RS-100-12 View
Have a BOM? Reply to our confirmation email with the file attached.
We use your details only to answer this request.

Technical data source

Primary source
MEAN WELL
Datasheet revision
2024-11-22
Last verified

View the manufacturer datasheet How we source and verify product data

Specifications are transcribed from the manufacturer datasheet and are subject to change without notice. The current manufacturer datasheet governs in case of any discrepancy.
