MEAN WELL RPS-65-5 50W 5V 10A Open Frame

Part numberRPS-65-5
Output voltage 5 V
Rated current 10 A
Rated power 50 W
$25.26Excluding tax and shipping
Ships in 3–5 business daysLead time is the time from order to dispatch, and does not include transit time.
Request bulk quote
RPS-65 model selection table Medical - PCB Type
  • Genuine product Sourced through our documented supply chain.
  • Worldwide shipping Export documentation handled for you.
  • Commercial invoice Available for every order.
  • Specification support Talk to someone who reads datasheets.

Key specifications

Complete technical specifications
Output
Output voltage 5 V
Rated current 10 A
Rated power 50 W
AC input range 80–264 VAC
Mechanical
Cooling Free-air convection
Operating temperature -30 to 70 °C
Dimensions (L × W × H) 76.2 × 50.8 × 24 mm

Is this model right for you?

The RPS-65-5 lists 80 ~ 264VAC input, the same as the other models in the RPS-65 series. They are distinguished by details this page does not carry; the datasheet lists them in full.

Product overview

The RPS-65-5 is an AC/DC open frame product in the MEAN WELL Medical - PCB Type family. It lists an input voltage range of 80 ~ 264VAC and a frequency range of 47 ~ 63Hz. The product measures 76.2 × 50.8 × 24 mm and has a net weight of 110 g.

Where this model fits

The RPS-65-5 is used in Embedded & Board-level Design. Its dimensions are 76.2 × 50.8 × 24 mm and its net weight is 110 g. The input voltage range is 80 ~ 264VAC with a frequency range of 47 ~ 63Hz.

Complete technical specifications

Output
Output voltage 5 V
Rated current 10 A
Rated power 50 W
Input
AC input range 80–264 VAC
Frequency range 47–63 Hz
Environmental
Operating temperature -30 to 70 °C
Storage temperature -40 to 85 °C
Vibration 10 ~ 500Hz, 2G 10min./1cycle, period for 60min. each along X, Y, Z axes
Mechanical
Dimensions (L × W × H) 76.2 × 50.8 × 24 mm
Net weight 110.0 g
Cooling Free-air convection
Fan Not supported
Identification
Part number RPS-65-5
Brand MEAN WELL
Category AC/DC Open Frame
Series RPS-65

Approvals and compliance

From the manufacturer's datasheet for this series
Isolation and electromagnetic compatibility
Withstand voltage I/P-O/P: 4KVAC
EMC emission Parameter Standard Test Level / Note

Certificates

Certificate copy supplied with this model.

  • CE · R50453592

    100%
    CE certificate R50453592

    CE · Certificate number R50453592

Ordering & shipping information

Order and delivery terms
Part number RPS-65-5
Minimum order quantity 1
Country of origin China
Typical packed weight 268 g
Unit weight 110 g

Downloads

RPS-65 model comparison

View all models
ModelOutput voltageRated currentRated powerPriceAvailability
RPS-65-5 5 V10 A50 W$25.26
Ships in 3–5 business days
RPS-65-1515 V4.34 A65.1 W$25.26
Ships in 3–5 business days
RPS-65-1212 V5.42 A65 W$23.37
Ships in 3–5 business days
