MEAN WELL RPB-1600-48 1584W 57.6V 27.5A Charger

Part numberRPB-1600-48
Output voltage 57.6 V
Rated current 27.5 A
Rated power 1584 W
$948.45Excluding tax and shipping
Ships in 3–5 business daysLead time is the time from order to dispatch, and does not include transit time.
Request bulk quote
RPB-1600 model selection table DBU/RPB Series
  • Genuine product Sourced through our documented supply chain.
  • Worldwide shipping Export documentation handled for you.
  • Commercial invoice Available for every order.
  • Specification support Talk to someone who reads datasheets.

Key specifications

Complete technical specifications
Output
Output voltage 57.6 V
Rated current 27.5 A
Rated power 1584 W
AC input range 90–264 VAC
Typical efficiency 93.5 %
Mechanical
Operating temperature -30 to 70 °C
Power factor correction Supported
Dimensions (L × W × H) 300 × 85 × 41 mm

Is this model right for you?

Within the RPB-1600 series, the RPB-1600-48 lists a typical efficiency of 93.5%, while RPB-1600-12 lists 91% and RPB-1600-24 lists 92.5%. Use the efficiency figure to distinguish these three models when other specifications are shared.

Product overview

The RPB-1600-48 is an AC/DC charger from MEAN WELL's RPB-1600 series. It lists a typical efficiency of 93.5% and an input range of 90 ~ 264VAC or 250 ~ 370VDC at 47 ~ 63Hz. The unit measures 300 × 85 × 41 mm and has a net weight of 2100 g. Humidity range is 20 to 90% and operating temperature range is -30 to 70 °C.

Where this model fits

The RPB-1600-48 is used in Battery Charging & Energy Storage and Renewable Energy & Off-grid Power. Its operating temperature range is -30 to 70 °C and humidity range is 20 to 90%. The unit measures 300 × 85 × 41 mm and weighs 2100 g.

Complete technical specifications

Rev. 2026-06-15
Output
Output voltage 57.6 V
Rated current 27.5 A
Rated power 1584 W
Input
AC input range 90–264 VAC
DC input range 250–370 VDC
Frequency range 47–63 Hz
Typical efficiency 93.5 %
Power factor 0.97
Power factor correction Supported
Protection
Over temperature Protected
Environmental
Operating temperature -30 to 70 °C
Storage temperature -40 to 85 °C
Operating humidity 20–90 % RH
Vibration 10 ~ 500Hz, 2G 10min./1cycle, 60min. each along X, Y, Z axes
Mechanical
Dimensions (L × W × H) 300 × 85 × 41 mm
Net weight 2100.0 g
Safety & compliance
Safety standards UL62368-1, TUV BS EN/EN62368-1, EAC TP TC 004 approved

These approvals are recorded for the series as a whole. Where a line names particular models or ratings, it applies only to those — read it against this part number, and ask us for the certificate if your approval process needs it.

Identification
Part number RPB-1600-48
Brand MEAN WELL
Category AC/DC Charger
Series RPB-1600

Approvals and compliance

From the manufacturer's datasheet for this series

United States

  • UL

    UL Listing or Recognition means UL Solutions tested samples against the applicable UL safety standard and audits the factory that builds them. A UL file number is the usual evidence an inspector or specifier asks for in North America.

Europe

  • TÜV

    A TÜV certificate is third-party testing against the European EN standard. It is the evidence behind a CE declaration rather than a replacement for it: CE remains the manufacturer's own declaration, and the TÜV report is what makes that declaration defensible.

Eurasian Economic Union

  • EAC

    Conformity with the Eurasian Economic Union technical regulations, covering Russia, Belarus, Kazakhstan, Armenia and Kyrgyzstan. TP TC 004 is the low-voltage regulation and TP TC 020 the electromagnetic-compatibility one, so which number appears tells you what was assessed.

Isolation and electromagnetic compatibility
Withstand voltage I/P-O/P:3KVAC I/P-FG:2KVAC O/P-FG:1.5KVAC
EMC emission Compliance to BS EN/EN55032 (CISPR32) Conduction Class B, Radiation Class A ; BS EN/EN61000-3-2,-3, EAC TP TC 020
EMC immunity Compliance to BS EN/EN61000-4-2,3,4,5,6,8,11, BS EN/EN55035, EAC TP TC 020

Standards certified against

  • EN62368-1
  • UL62368-1
Read the datasheet's exact wording

UL62368-1, TUV BS EN/EN62368-1, EAC TP TC 004 approved

Reproduced unedited from the manufacturer's datasheet. Where an approval covers only some models, the wording says so. Ask us for the certificate itself if your approval process needs it.

Certificates

Certificate copy supplied with this model.

  • CE · R50453592

    100%
    CE certificate R50453592

    CE · Certificate number R50453592

Ordering & shipping information

Order and delivery terms
Part number RPB-1600-48
Minimum order quantity 1
Country of origin China
Typical packed weight 2491 g
Unit weight 2100 g

Downloads

RPB-1600 model comparison

View all models
ModelOutput voltageRated currentRated powerPriceAvailability
RPB-1600-48 57.6 V27.5 A1584 W$948.45
Ships in 3–5 business days
RPB-1600-1214.4 V100 A1440 W$948.45
Ships in 3–5 business days

RPB-1600-48 lists a typical efficiency of 93.5%, compared with 91% for RPB-1600-12 and 92.5% for RPB-1600-24.

Request a bulk quote

Tell us the quantity and target date and we will come back with pricing, lead time and stock position for this part number.

  1. 1 We confirm the part number and quantity against current stock.
  2. 2 You receive pricing, lead time and freight options by email.
  3. 3 Approve the quotation and we issue the invoice and shipping documents.

Request a quote for RPB-1600-48

Confirm quantity and destination and we will come back with pricing and lead time.

Quoting RPB-1600-48 View
Have a BOM? Reply to our confirmation email with the file attached.
We use your details only to answer this request.

Technical data source

Primary source
MEAN WELL
Datasheet revision
2026-06-15
Last verified

View the manufacturer datasheet How we source and verify product data

Specifications are transcribed from the manufacturer datasheet and are subject to change without notice. The current manufacturer datasheet governs in case of any discrepancy.
