MEAN WELL NPP-750-48 759.36W 57.6V 11.3A Charger

Part numberNPP-750-48
Output voltage 57.6 V
Rated current 11.3 A
Rated power 759.36 W
$299.09Excluding tax and shipping
Ships in 3–5 business daysLead time is the time from order to dispatch, and does not include transit time.
Request bulk quote
NPP-750 model selection table NPP Series
  • Genuine product Sourced through our documented supply chain.
  • Worldwide shipping Export documentation handled for you.
  • Commercial invoice Available for every order.
  • Specification support Talk to someone who reads datasheets.

Key specifications

Complete technical specifications
Output
Output voltage 57.6 V
Rated current 11.3 A
Rated power 759.36 W
AC input range 90–264 VAC
Typical efficiency 93 %
Mechanical
Operating temperature -30 to 70 °C
Power factor correction Supported
Dimensions (L × W × H) 230 × 158 × 67 mm

Is this model right for you?

Within the NPP-750 series, the NPP-750-48 provides 57.6 V output and 11.3 A output current. The NPP-750-24 provides 28.8 V and 22.5 A, while the NPP-750-12 provides 14.4 V and 43 A. Rated power differs: NPP-750-48 lists 759.36 W, NPP-750-24 lists 756 W, and NPP-750-12 lists 722.4 W.

Product overview

The NPP-750-48 is an AC/DC Charger in the NPP-750 series. It lists a 57.6 V output voltage, 11.3 A output current, and 759.36 W rated power. Typical efficiency is 93%. The input voltage range is 90 ~ 264VAC 127 ~ 370VDC, with a frequency range of 47 ~ 63Hz. Ripple and noise is 480mVp-p. Dimensions are 230 × 158 × 67 mm and net weight is 1840 g.

Where this model fits

The NPP-750-48 is used in Battery Charging & Energy Storage and Renewable Energy & Off-grid Power. Its 57.6 V output and 11.3 A output current are the electrical figures for this model. The operating temperature range is -30 to 70 °C and humidity range is 20 to 95%.

Complete technical specifications

Rev. 2026-07-06
Output
Output voltage 57.6 V
Rated current 11.3 A
Rated power 759.36 W
Ripple & noise 480 mVp-p
Input
AC input range 90–264 VAC
DC input range 127–370 VDC
Frequency range 47–63 Hz
Typical efficiency 93 %
Power factor 0.98
Power factor correction Supported
Protection
Short circuit Protected
Over voltage Protected
Over temperature Protected
Shut down and latch off o/p voltage, re-power on to recover
Environmental
Operating temperature -30 to 70 °C
Storage temperature -40 to 85 °C
Operating humidity 20–95 % RH
Vibration 10 ~ 500Hz, 2G 10min./1cycle, 60min. each along X, Y, Z axes
Mechanical
Dimensions (L × W × H) 230 × 158 × 67 mm
Net weight 1840.0 g
Safety & compliance
Safety standards CB IEC62368-1,IEC60335-1/2-29, Dekra BS EN/EN62368-1,BS EN/EN60335-1/2-29, UL62368-1, J62368-1, EAC TP TC 004 approved

These approvals are recorded for the series as a whole. Where a line names particular models or ratings, it applies only to those — read it against this part number, and ask us for the certificate if your approval process needs it.

Identification
Part number NPP-750-48
Brand MEAN WELL
Category AC/DC Charger
Series NPP-750

Approvals and compliance

From the manufacturer's datasheet for this series
Isolation and electromagnetic compatibility
Withstand voltage I/P-O/P:3KVAC I/P-FG:2KVAC O/P-FG:0.5KVAC
Isolation resistance I/P-O/P, I/P-FG, O/P-FG:100M Ohms / 500VDC / 25℃/ 70% RH
EMC emission Parameter Standard Test Level / Note

Standards certified against

  • EN60335-1/2-29
  • EN62368-1
  • IEC60335-1/2-29
  • IEC62368-1
  • J62368-1
  • UL62368-1
Read the datasheet's exact wording

CB IEC62368-1,IEC60335-1/2-29, Dekra BS EN/EN62368-1,BS EN/EN60335-1/2-29, UL62368-1, J62368-1, EAC TP TC 004 approved

Reproduced unedited from the manufacturer's datasheet. Where an approval covers only some models, the wording says so. Ask us for the certificate itself if your approval process needs it.

Certificates

Certificate copy supplied with this model.

  • CE · R50453592

    100%
    CE certificate R50453592

    CE · Certificate number R50453592

Ordering & shipping information

Order and delivery terms
Part number NPP-750-48
Minimum order quantity 1
Country of origin China
Typical packed weight 2473 g
Unit weight 1840 g

Downloads

NPP-750 model comparison

View all models
ModelOutput voltageRated currentRated powerPriceAvailability
NPP-750-2428.8 V22.5 A756 W$299.09
Ships in 3–5 business days
NPP-750-48 57.6 V11.3 A759.36 W$299.09
Ships in 3–5 business days

NPP-750-48: 57.6 V output, 11.3 A output current; NPP-750-24: 28.8 V output, 22.5 A output current.

NPP-750-48: 57.6 V output, 11.3 A output current; NPP-750-12: 14.4 V output, 43 A output current.

NPP-750-48: 759.36 W rated power; NPP-750-24: 756 W rated power; NPP-750-12: 722.4 W rated power.

NPP-750-48: 480mVp-p ripple and noise; NPP-750-24: 300mVp-p; NPP-750-12: 180mVp-p.
