MEAN WELL EPP-300-48 300W 48V 6.25A Open Frame

Part numberEPP-300-48
Output voltage 48 V
Rated current 6.25 A
Rated power 300 W
$112.75Excluding tax and shipping
Ships in 3–5 business daysLead time is the time from order to dispatch, and does not include transit time.
Request bulk quote
EPP-300 model selection table Industrial - Green PCB Type
  • Genuine product Sourced through our documented supply chain.
  • Worldwide shipping Export documentation handled for you.
  • Commercial invoice Available for every order.
  • Specification support Talk to someone who reads datasheets.

Key specifications

Complete technical specifications
Output
Output voltage 48 V
Rated current 6.25 A
Rated power 300 W
AC input range 90–264 VAC
Typical efficiency 93 %
Mechanical
Operating temperature -30 to 70 °C
Power factor correction Supported
Dimensions (L × W × H) 127 × 76.2 × 35 mm

Is this model right for you?

EPP-300-48 provides a 48V main output with an adjustment range of Main output:45.6 ~ 50.4V, 250mVp-p ripple noise, and 93% typical efficiency. Sibling variants differ: EPP-300-12 provides 12V with Main output:11.4 ~ 12.6V adjustment, 120mVp-p ripple noise, and 90% typical efficiency; EPP-300-15 provides 15V with Main output:14.25 ~ 15.75V adjustment, 120mVp-p ripple noise, and 90% typical efficiency; EPP-300-24 provides 24V with Main output:22.8 ~ 25.2V adjustment, 150mVp-p ripple noise, and 92.5% typical efficiency; EPP-300-27 provides 27V with Main output:25.65 ~ 28.35V adjustment and 200mVp-p ripple noise.

Product overview

The MEAN WELL EPP-300-48 is an AC/DC Open Frame product in the EPP-300 series with 48 V output at 6.25 A, 300 W rated power, 90 ~ 264VAC 127 ~ 370VDC at 47 ~ 63Hz input.

Complete technical specifications

Rev. 2026-03-31
Output
Output voltage 48 V
Rated current 6.25 A
Rated power 300 W
Voltage adjustment range 45.6–50.4 V
Ripple & noise 250 mVp-p
Input
AC input range 90–264 VAC
DC input range 127–370 VDC
Frequency range 47–63 Hz
Typical efficiency 93 %
Power factor 0.93
Power factor correction Supported
Environmental
Operating temperature -30 to 70 °C
Storage temperature -40 to 85 °C
Operating humidity 20–90 % RH
Vibration 10 ~ 500Hz, 2G 10min./1cycle, 60min. each along X, Y, Z axes
Mechanical
Dimensions (L × W × H) 127 × 76.2 × 35 mm
Net weight 370.0 g
Safety & compliance
Safety standards UL62368-1, TUV BS EN/EN62368-1, EAC TP TC 004 approved

These approvals are recorded for the series as a whole. Where a line names particular models or ratings, it applies only to those — read it against this part number, and ask us for the certificate if your approval process needs it.

Identification
Part number EPP-300-48
Brand MEAN WELL
Category AC/DC Open Frame
Series EPP-300

Approvals and compliance

From the manufacturer's datasheet for this series

United States

  • UL

    UL Listing or Recognition means UL Solutions tested samples against the applicable UL safety standard and audits the factory that builds them. A UL file number is the usual evidence an inspector or specifier asks for in North America.

Europe

  • TÜV

    A TÜV certificate is third-party testing against the European EN standard. It is the evidence behind a CE declaration rather than a replacement for it: CE remains the manufacturer's own declaration, and the TÜV report is what makes that declaration defensible.

Eurasian Economic Union

  • EAC

    Conformity with the Eurasian Economic Union technical regulations, covering Russia, Belarus, Kazakhstan, Armenia and Kyrgyzstan. TP TC 004 is the low-voltage regulation and TP TC 020 the electromagnetic-compatibility one, so which number appears tells you what was assessed.

Isolation and electromagnetic compatibility
Withstand voltage I/P-O/P:3KVAC I/P-FG:2KVAC O/P-FG:0.5KVAC
Isolation resistance I/P-O/P, I/P-FG, O/P-FG:100M Ohms / 500VDC / 25℃/ 70% RH
EMC emission Compliance to BS EN/EN55032 (CISPR32),Conduction Class B,Radiation Class B;BS EN/EN61000-3-2,3;EAC TP TC 020
EMC immunity Compliance to BS EN/EN61000-4-2,3,4,5,6,8,11, BS EN/EN55035, BS EN/EN60601-1-2, EAC TP TC 020

Standards certified against

  • EN62368-1
  • UL62368-1
Read the datasheet's exact wording

UL62368-1, TUV BS EN/EN62368-1, EAC TP TC 004 approved

Reproduced unedited from the manufacturer's datasheet. Where an approval covers only some models, the wording says so. Ask us for the certificate itself if your approval process needs it.

Certificates

Certificate copy supplied with this model.

  • CE · R50453592

    100%
    CE certificate R50453592

    CE · Certificate number R50453592

Ordering & shipping information

Order and delivery terms
Part number EPP-300-48
Minimum order quantity 1
Country of origin China
Typical packed weight 547 g
Unit weight 370 g

Downloads

EPP-300 model comparison

View all models
ModelOutput voltageRated currentRated powerPriceAvailability
EPP-300-48 48 V6.25 A300 W$112.75
Ships in 3–5 business days
EPP-300-2424 V12.5 A300 W$104.85
Ships in 3–5 business days

EPP-300-48: 48 V output; the rest of the series runs 12 V to 27 V.

EPP-300-48: 6.25 A output current; the rest of the series runs 11.1 A to 25 A.

EPP-300-48: 93% typical efficiency; EPP-300-12 and EPP-300-15: 90%; EPP-300-24: 92.5%.

EPP-300-48: Main output:45.6 ~ 50.4V adjustment range; elsewhere in the series: Main output:11.4 ~ 12.6V, Main output:14.25 ~ 15.75V, Main output:22.8 ~ 25.2V.

Request a bulk quote

Tell us the quantity and target date and we will come back with pricing, lead time and stock position for this part number.

  1. 1 We confirm the part number and quantity against current stock.
  2. 2 You receive pricing, lead time and freight options by email.
  3. 3 Approve the quotation and we issue the invoice and shipping documents.

Request a quote for EPP-300-48

Confirm quantity and destination and we will come back with pricing and lead time.

Quoting EPP-300-48 View
Have a BOM? Reply to our confirmation email with the file attached.
We use your details only to answer this request.

Technical data source

Primary source
MEAN WELL
Datasheet revision
2026-03-31
Last verified

View the manufacturer datasheet How we source and verify product data

Specifications are transcribed from the manufacturer datasheet and are subject to change without notice. The current manufacturer datasheet governs in case of any discrepancy.
