MEAN WELL DRS-480-48 480W 48V 10A Security & Specific

Part numberDRS-480-48
Output voltage 48 V
Rated current 10 A
Rated power 480 W
$381.52Excluding tax and shipping
Ships in 3–5 business daysLead time is the time from order to dispatch, and does not include transit time.
Request bulk quote
DRS-480 model selection table Security—DRS
  • Genuine product Sourced through our documented supply chain.
  • Worldwide shipping Export documentation handled for you.
  • Commercial invoice Available for every order.
  • Specification support Talk to someone who reads datasheets.

Key specifications

Complete technical specifications
Output
Output voltage 48 V
Rated current 10 A
Rated power 480 W
AC input range 90–305 VAC
Typical efficiency 93.5 %
Mechanical
Operating temperature -30 to 70 °C
Power factor correction Supported
Dimensions (L × W × H) 110 × 125.2 × 150.7 mm

Is this model right for you?

Within the DRS-480 series, the DRS-480-48 lists 48 V, 93.5%. By comparison DRS-480-24 lists 24 V, 92.5%; DRS-480-36 lists 36 V, 93.5%. Select the model whose output voltage matches the installation.

Product overview

The DRS-480-48 belongs to the MEAN WELL DRS-480 series within the Security—DRS family. Its input range covers 90 ~ 305VAC and 127 ~ 431VDC, with a frequency range of 47 ~ 63Hz. The product measures 110 × 125.2 × 150.7 mm and has a net weight of 1920 g. Operating temperature spans -30 to 70 °C, and humidity ranges from 20 to 90%.

Where this model fits

The DRS-480-48 is used in Security & Surveillance applications, where equipment such as CCTV cameras, access control, and intruder alarms is typically fed from a central cabinet. Its operating temperature range of -30 to 70 °C and humidity range of 20 to 90% are relevant where equipment sits outside a heated building. The product measures 110 × 125.2 × 150.7 mm and weighs 1920 g.

Complete technical specifications

Rev. 2026-06-08
Output
Output voltage 48 V
Rated current 10 A
Rated power 480 W
Input
AC input range 90–305 VAC
DC input range 127–431 VDC
Frequency range 47–63 Hz
Typical efficiency 93.5 %
Power factor 0.95
Power factor correction Supported
Protection
Overload Protected
Over voltage Protected
Over temperature Protected
Reverse polarity Protected
Constant current limiting, shutdown output voltage after 5 sec.
Environmental
Operating temperature -30 to 70 °C
Storage temperature -40 to 85 °C
Operating humidity 20–90 % RH
Vibration 10 ~ 500Hz, 5G 10min./1cycle, 60min. each along X, Y, Z axes
Mechanical
Dimensions (L × W × H) 110 × 125.2 × 150.7 mm
Net weight 1920.0 g
Safety & compliance
Safety standards UL62368-1, Dekra BS EN/EN62368-1, RCM AS/NZS 62368.1, EAC TP TC 004 approved

These approvals are recorded for the series as a whole. Where a line names particular models or ratings, it applies only to those — read it against this part number, and ask us for the certificate if your approval process needs it.

Identification
Part number DRS-480-48
Brand MEAN WELL
Category AC/DC Security & Specific
Series DRS-480

Approvals and compliance

From the manufacturer's datasheet for this series

United States

  • UL

    UL Listing or Recognition means UL Solutions tested samples against the applicable UL safety standard and audits the factory that builds them. A UL file number is the usual evidence an inspector or specifier asks for in North America.

Europe

  • DEKRA

    DEKRA is a European notified body; a DEKRA certificate on a datasheet is third-party testing against the cited EN standard, equivalent in standing to a TÜV one.

Eurasian Economic Union

  • EAC

    Conformity with the Eurasian Economic Union technical regulations, covering Russia, Belarus, Kazakhstan, Armenia and Kyrgyzstan. TP TC 004 is the low-voltage regulation and TP TC 020 the electromagnetic-compatibility one, so which number appears tells you what was assessed.

Australia and New Zealand

  • RCMSupplier declaration

    The Regulatory Compliance Mark covers electrical safety and electromagnetic compatibility for Australia and New Zealand. It is applied by a registered local supplier against an AS/NZS standard, which is why the datasheet cites AS/NZS numbers alongside it.

Isolation and electromagnetic compatibility
Withstand voltage I/P-O/P: 4KVAC I/P-FG: 2KVAC O/P-FG: 1.5KVAC
Isolation resistance I/P-O/P, I/P-FG, O/P-FG: 100M Ohms/500VDC/25℃/ 70%RH
EMC emission Parameter Standard Test Level / Note

Standards certified against

  • AS/NZS 62368.1
  • EN62368-1
  • UL62368-1
Read the datasheet's exact wording

UL62368-1, Dekra BS EN/EN62368-1, RCM AS/NZS 62368.1, EAC TP TC 004 approved

Reproduced unedited from the manufacturer's datasheet. Where an approval covers only some models, the wording says so. Ask us for the certificate itself if your approval process needs it.

Certificates

Certificate copy supplied with this model.

  • CE · R50453592

    100%
    CE certificate R50453592

    CE · Certificate number R50453592

Ordering & shipping information

Order and delivery terms
Part number DRS-480-48
Minimum order quantity 1
Country of origin China
Typical packed weight 2295 g
Unit weight 1920 g

Downloads

DRS-480 model comparison

View all models
ModelOutput voltageRated currentRated powerPriceAvailability
DRS-480-48 48 V10 A480 W$381.52
Ships in 3–5 business days
DRS-480-2424 V20 A480 W$381.52
Ships in 3–5 business days

DRS-480-48: 48 V output; DRS-480-24: 24 V; DRS-480-36: 36 V.

DRS-480-48: 10 A output current; DRS-480-36: 13.3 A; DRS-480-24: 20 A.

DRS-480-48: 93.5% typical efficiency; DRS-480-24: 92.5%.

Request a bulk quote

Tell us the quantity and target date and we will come back with pricing, lead time and stock position for this part number.

  1. 1 We confirm the part number and quantity against current stock.
  2. 2 You receive pricing, lead time and freight options by email.
  3. 3 Approve the quotation and we issue the invoice and shipping documents.

Request a quote for DRS-480-48

Confirm quantity and destination and we will come back with pricing and lead time.

Quoting DRS-480-48 View
Have a BOM? Reply to our confirmation email with the file attached.
We use your details only to answer this request.

Technical data source

Primary source
MEAN WELL
Datasheet revision
2026-06-08
Last verified

View the manufacturer datasheet How we source and verify product data

Specifications are transcribed from the manufacturer datasheet and are subject to change without notice. The current manufacturer datasheet governs in case of any discrepancy.
