MEAN WELL DDRH-60-5 50W 5V 10A DIN Rail

Part numberDDRH-60-5
Output voltage 5 V
Rated current 10 A
Rated power 50 W
$88.43Excluding tax and shipping
Ships in 3–5 business daysLead time is the time from order to dispatch, and does not include transit time.
Request bulk quote
DDRH-60 model selection table DDRH-60 Series
  • Genuine product Sourced through our documented supply chain.
  • Worldwide shipping Export documentation handled for you.
  • Commercial invoice Available for every order.
  • Specification support Talk to someone who reads datasheets.

Key specifications

Complete technical specifications
Output
Output voltage 5 V
Rated current 10 A
Rated power 50 W
Mechanical
Operating temperature -30 to 80 °C
Dimensions (L × W × H) 57 × 93.5 × 105 mm

Is this model right for you?

Within the DDRH-60 series, the DDRH-60-5 differs from siblings by output voltage, output current, rated power, output adjustment range, and ripple and noise. DDRH-60-5: 5V, 10A, 50W, 5 ~ 6V, 100mVp-p. DDRH-60-12: 12V, 5A, 60W, 12 ~ 15V, 120mVp-p. DDRH-60-24: 24V, 2.5A, 60W, 24 ~ 29V, 150mVp-p. DDRH-60-48: 48V, 1.25A, 60W, 48 ~ 54V, 200mVp-p.

Product overview

The DDRH-60-5 provides a 5V output with 10A output current and 50W rated power. Its input voltage range is 150 ~ 1500Vdc, and the output adjustment range is 5 ~ 6V. Ripple and noise are listed at 100mVp-p. The product measures 57 × 93.5 × 105 mm and has a net weight of 800g.

Where this model fits

The DDRH-60-5 is used in Industrial Automation. Its 5V output and 10A output current are the electrical figures for this model. The product measures 57 × 93.5 × 105 mm and has a net weight of 800g.

Complete technical specifications

Rev. 2026-03-31
Output
Output voltage 5 V
Rated current 10 A
Rated power 50 W
Voltage adjustment range 5–6 V
Ripple & noise 100 mVp-p
Input
AC input range 150 ~ 1500Vdc
DC input range 150–1500 VDC
Protection
Reverse polarity Protected
Environmental
Operating temperature -30 to 80 °C
Storage temperature -40 to 80 °C
Operating humidity 20–90 % RH
Vibration Component: 10 ~ 500Hz, 3G 10min./1cycle, 60min. each along X, Y, Z axes; Mounting clip: Compliance to IEC60068-2-6
Mechanical
Dimensions (L × W × H) 57 × 93.5 × 105 mm
Net weight 800.0 g
Safety & compliance
Safety standards UL1741, CSA C22.2 No.107.1-16 , IEC62109-1(LVD) , EAC TP TC 004 approved

These approvals are recorded for the series as a whole. Where a line names particular models or ratings, it applies only to those — read it against this part number, and ask us for the certificate if your approval process needs it.

Identification
Part number DDRH-60-5
Brand MEAN WELL
Category DC/DC DIN Rail
Series DDRH-60

Approvals and compliance

From the manufacturer's datasheet for this series

United States

  • UL

    UL Listing or Recognition means UL Solutions tested samples against the applicable UL safety standard and audits the factory that builds them. A UL file number is the usual evidence an inspector or specifier asks for in North America.

Canada

  • CSA

    Certification to a CSA C22.2 standard, the Canadian counterpart of the UL series. Datasheets cite the specific C22.2 number, which is how you tell a power-supply certificate from a luminaire-controlgear one.

Eurasian Economic Union

  • EAC

    Conformity with the Eurasian Economic Union technical regulations, covering Russia, Belarus, Kazakhstan, Armenia and Kyrgyzstan. TP TC 004 is the low-voltage regulation and TP TC 020 the electromagnetic-compatibility one, so which number appears tells you what was assessed.

Isolation and electromagnetic compatibility
Withstand voltage I/P-O/P:4KVAC O/P-DC OK:0.5KVAC

Standards certified against

  • IEC62109-1
  • UL1741
Read the datasheet's exact wording

UL1741, CSA C22.2 No.107.1-16 , IEC62109-1(LVD) , EAC TP TC 004 approved

Reproduced unedited from the manufacturer's datasheet. Where an approval covers only some models, the wording says so. Ask us for the certificate itself if your approval process needs it.

Certificates

Certificate copy supplied with this model.

  • CE · R50453592

    100%
    CE certificate R50453592

    CE · Certificate number R50453592

Ordering & shipping information

Order and delivery terms
Part number DDRH-60-5
Minimum order quantity 1
Country of origin China
Typical packed weight 950 g
Unit weight 800 g

Downloads

DDRH-60 model comparison

View all models
ModelOutput voltageRated currentRated powerPriceAvailability
DDRH-60-2424 V2.5 A60 W$88.43
Ships in 3–5 business days
DDRH-60-5 5 V10 A50 W$88.43
Ships in 3–5 business days

DDRH-60-5 provides 5V output and 10A output current; DDRH-60-12 provides 12V output and 5A output current.

DDRH-60-5 has 50W rated power; DDRH-60-24 has 60W rated power.

DDRH-60-5 lists 100mVp-p ripple and noise; DDRH-60-48 lists 200mVp-p ripple and noise.

DDRH-60-5 has a 5 ~ 6V output adjustment range; DDRH-60-24 has a 24 ~ 29V output adjustment range.

Request a bulk quote

Tell us the quantity and target date and we will come back with pricing, lead time and stock position for this part number.

  1. 1 We confirm the part number and quantity against current stock.
  2. 2 You receive pricing, lead time and freight options by email.
  3. 3 Approve the quotation and we issue the invoice and shipping documents.

Request a quote for DDRH-60-5

Confirm quantity and destination and we will come back with pricing and lead time.

Quoting DDRH-60-5 View
Have a BOM? Reply to our confirmation email with the file attached.
We use your details only to answer this request.

Technical data source

Primary source
MEAN WELL
Datasheet revision
2026-03-31
Last verified

How we source and verify product data

Specifications are transcribed from the manufacturer datasheet and are subject to change without notice. The current manufacturer datasheet governs in case of any discrepancy.
