MEAN WELL CSP-3000-400 3000W 400V 7.5A Programmable Power

Part numberCSP-3000-400
Output voltage 400 V
Rated current 7.5 A
Rated power 3000 W
$628.19Excluding tax and shipping
Ships in 3–5 business daysLead time is the time from order to dispatch, and does not include transit time.
Request bulk quote
CSP-3000 model selection table CSP Series
  • Genuine product Sourced through our documented supply chain.
  • Worldwide shipping Export documentation handled for you.
  • Commercial invoice Available for every order.
  • Specification support Talk to someone who reads datasheets.

Key specifications

Complete technical specifications
Output
Output voltage 400 V
Rated current 7.5 A
Rated power 3000 W
AC input range 180–264 VAC
Typical efficiency 93 %
Mechanical
Operating temperature -20 to 65 °C
Power factor correction Supported
Dimensions (L × W × H) 278 × 177.8 × 63.5 mm

Is this model right for you?

CSP-3000 series output voltage differs by model: CSP-3000-400 provides 400V, CSP-3000-250 provides 250V, and CSP-3000-120 provides 120V. Output current differs accordingly: CSP-3000-400 provides 7.5A, CSP-3000-250 provides 12A, and CSP-3000-120 provides 25A. Ripple noise is listed at 1200mVp-p for the CSP-3000-400, 1000mVp-p for the CSP-3000-250, and 800mVp-p for the CSP-3000-120. Typical efficiency is 93% for the CSP-3000-400, 92.5% for the CSP-3000-250, and 92% for the CSP-3000-120. Select a model by the output voltage and current combination it lists.

Product overview

The MEAN WELL CSP-3000-400 is a Programmable Power product in the CSP-3000 series. It provides a rated power of 3000W with a 400V output at 7.5A. Typical efficiency is listed at 93%. The input operates across 180 ~ 264VAC / 254 ~ 370VDC with a 47~63Hz frequency range. Ripple noise is specified at 1200mVp-p. The product measures 278*177.8*63.5mm (L*W*H). Among the CSP-3000 models, the 400V output voltage of the CSP-3000-400 is the highest listed value.

Complete technical specifications

Rev. 2025-08-08
Output
Output voltage 400 V
Rated current 7.5 A
Rated power 3000 W
Ripple & noise 1200 mVp-p
Input
AC input range 180–264 VAC
DC input range 254–370 VDC
Frequency range 47–63 Hz
Typical efficiency 93 %
Power factor 0.95
Power factor correction Supported
Environmental
Operating temperature -20 to 65 °C
Storage temperature -40 to 85 °C
Operating humidity 20–90 % RH
Vibration 10 ~ 500Hz, 2G 10min./1cycle, 60min. each along X, Y, Z axes
Mechanical
Dimensions (L × W × H) 278 × 177.8 × 63.5 mm
Net weight 3500.0 g
Safety & compliance
Safety standards UL62368-1, BS EN/EN62368-1, EAC TP TC004, GB4943.1

These approvals are recorded for the series as a whole. Where a line names particular models or ratings, it applies only to those — read it against this part number, and ask us for the certificate if your approval process needs it.

Identification
Part number CSP-3000-400
Brand MEAN WELL
Category AC/DC Programmable Power
Series CSP-3000

Approvals and compliance

From the manufacturer's datasheet for this series

United States

  • UL

    UL Listing or Recognition means UL Solutions tested samples against the applicable UL safety standard and audits the factory that builds them. A UL file number is the usual evidence an inspector or specifier asks for in North America.

Eurasian Economic Union

  • EAC

    Conformity with the Eurasian Economic Union technical regulations, covering Russia, Belarus, Kazakhstan, Armenia and Kyrgyzstan. TP TC 004 is the low-voltage regulation and TP TC 020 the electromagnetic-compatibility one, so which number appears tells you what was assessed.

Isolation and electromagnetic compatibility
Withstand voltage I/P-O/P:3KVAC I/P-FG:2KVAC O/P-FG:0.5KVAC
Isolation resistance I/P-O/P, I/P-FG, O/P-FG:100M Ohms / 500VDC / 25℃/ 70% RH

Standards certified against

  • EN62368-1
  • GB4943.1
  • UL62368-1
Read the datasheet's exact wording

UL62368-1, BS EN/EN62368-1, EAC TP TC004, GB4943.1

Reproduced unedited from the manufacturer's datasheet. Where an approval covers only some models, the wording says so. Ask us for the certificate itself if your approval process needs it.

Certificates

Certificate copy supplied with this model.

  • CE · R50453592

    100%
    CE certificate R50453592

    CE · Certificate number R50453592

Ordering & shipping information

Order and delivery terms
Part number CSP-3000-400
Minimum order quantity 1
Country of origin China
Warranty 5-year limited warranty, subject to the conditions in MEAN WELL's published warranty statement.
Typical packed weight 3905 g
Unit weight 3500 g

Downloads

CSP-3000 model comparison

View all models
ModelOutput voltageRated currentRated powerPriceAvailability
CSP-3000-120120 V25 A3000 W$628.19
Ships in 3–5 business days
CSP-3000-400 400 V7.5 A3000 W$628.19
Ships in 3–5 business days
CSP-3000-250250 V12 A3000 W$628.19
Ships in 3–5 business days

Output voltage: CSP-3000-400 400V; CSP-3000-250 250V; CSP-3000-120 120V.

Output current: CSP-3000-400 7.5A; CSP-3000-250 12A; CSP-3000-120 25A.

Ripple noise: CSP-3000-400 1200mVp-p; CSP-3000-250 1000mVp-p; CSP-3000-120 800mVp-p.

Typical efficiency: CSP-3000-400 93%; CSP-3000-250 92.5%; CSP-3000-120 92%.

Request a bulk quote

Tell us the quantity and target date and we will come back with pricing, lead time and stock position for this part number.

  1. 1 We confirm the part number and quantity against current stock.
  2. 2 You receive pricing, lead time and freight options by email.
  3. 3 Approve the quotation and we issue the invoice and shipping documents.

Request a quote for CSP-3000-400

Confirm quantity and destination and we will come back with pricing and lead time.

Quoting CSP-3000-400 View
Have a BOM? Reply to our confirmation email with the file attached.
We use your details only to answer this request.

Technical data source

Primary source
MEAN WELL
Datasheet revision
2025-08-08
Last verified

View the manufacturer datasheet How we source and verify product data

Specifications are transcribed from the manufacturer datasheet and are subject to change without notice. The current manufacturer datasheet governs in case of any discrepancy.
